TRANSACTIONAL CURRENCY SANITIZER

Stock Exchange

Perfect for commercial businesses that want peace of mind knowing that their money is clean against the fight on passing virus and bacteria.

MONEY SANITIZER.png

SPECIFICATIONS

  • High powered UVC  bulb (25 watts).

  • Secure locking drawer with key.

  • UV Resistant Acrylic Case.

  • Fits any type of US bank note or Canadian Polymer bill.

  • Light weight (less than five lbs.).

  • Dual 40 mm fans for double the cooling.

  • Double safety switch activation with a

  • Three second UVC bulb activation delay.

  • UVC Bulb turns off automatically after one minute of use.

  • Reprogrammable microcontroller unit (MCU) included.

  • Programming IDE for the MCU is free.

  • Removable panels for quick bulb and electronics servicing.

  • OSHA compliant for workplaces in the USA.

DIMENSIONS

  • Length: 12” (304 mm)


  • Width: 8.525” (234 mm [counting the handle])


  • Height: 7.714” (195.94 mm)


  • Weight: 4.58 lbs. (2.08 kgs) Without money

Carpenter Measuring Wood
Writing on Computer

SPECIFICATIONS

  • 25-Watt 110 Volt E26 UVC bulb with 15mg of mercury per bulb.

  • Post-processed black Acrylic.

  • McMaster-Carr Miniature Keyed Cam Lock with Straight and Offset Cam, for 1/2" Through Hole Diameter.  Made of polished Nickel-Plated Zinc.

  • RoHS 3 (2015/863/EU) Compliant (Cam lock)

  • REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant (Cam lock)

  • The whole unit runs off regular household AC outlets.

  • USB data cable provided for coding upgrades.

  • SAFETY RATED E26 light bulb socket adapter is designed with fire-resistant materials and is rated to sustain 110 to 125 volts and 375 watts; Light cord switch is compatible with E26 US standard screw-base .

  • DC 5-volt cooling fans that measure 40x40x10mm, Color: Blue LED Lights

  • Relay with normally open interfaces , maximum load: AC 250V/10A, DC 30V/10A.

Home Improvement

SOLUTIONS / BENEFITS

  • UVC  lamp is capable of inactivating the coronavirus and damaging the DNA of other hostile micro-organisms.

  • Ozone-free UVC bulbs can provide an odor-free sanitizing process.

  • Provides rapid cleaning power to currency using 25 watts of power that can clean 24 square inches per second.

  • The device provides a secure way to protect money against counterfeiting and or theft.

  • The Economy Version can be furnished with OSHA compliant stickers for safe UVC activation.

PRECAUTIONS

  • Please use UV ray resistant goggles or safety glasses while the unit is in operation.

  • United States workplaces require the OSHA sticker for UVC warning to be on the unit prior to activation.

  • Never touch the UVC bulb when it is in operation.

  • Please use be clothed and or use appropriate personal protective equipment (PPE) while using this design.

REFERENCE AND FURTHER STUDY
